Ever wondered if you could dual boot macOS and Windows on the same hard drive disk? With a Hackintosh, you can. While it’s typically better to have macOS on one drive and Windows on another, it’s possible to dual boot both operating systems on the same drive. The dual-boot option is ideal for those who don’t have multiple drives on hand.

How to Dual Boot Windows 10 and MacOS High Sierra on a Hackintosh

Microsoft office update for mac 2016. The first step in the process is to format the drive as GUID. To do this, you’ll need to use the Disk Utility application, which is the macOS equivalent of Disk Management in Windows.

Disk Utility can be accessed during the install or from within the operating system after the installation is complete.

There’s a very good reason for formatting the disc in the GUID format first. For starters, you’ll need this format to install macOS. But formatting with the Disk Utility will allow you to create a larger hidden EFI partition compared to what you would create with Windows Disk Management (200MB with GUID vs. 100MB with Windows). That extra space will allow you to fit both operating systems with room to spare.

In this article, I am going to show you how to dual boot Windows 10 and macOS Sierra on PC. Apple has already released the Macintosh operating system on 20 September of 2016, and if you want to give a try to this OS, then you are in the right place because here you will learn the complete process of how to dual boot Windows 10 and macOS Sierra 10.12, Hackintosh on PC.

• On a hackintosh it’s possible to dual boot macOS and Windows on the same hard drive disk, which I will explain how to here. Although it’s recommended that macOS be installed on a separate drive than Windows, it’s perfectly possible to dual boot Windows and macOS on the same drive for those that don’t have multiple hard drives to spare.
• Can run Windows apps without Windows OS: Runs All Windows Applications: Price: $39.95 — $59.95 and no Windows OS $119.99 for Win10 Home or $199.99 for Win10 Pro. $79.99 for Parallels, plus cost of Windows OS.

The Windows partition can be created either during the install or after the install. If you want the Windows partition to show up first, then you would want to create the partition during the install. If you want the macOS partition to show up first, then you can create the partition after the installation is completed.

In this guide, we’re going to install the Windows partition second. It’s a simpler, more straightforward way to get your dual-boot Hackintosh up and running.

Once you’ve formatted the drive as GUID, you can move on to the next step.

Access to macOS

After formatting the drive, the next step is to create a macOS flash drive installer. To do this, you’ll either need access to a Mac, or access to a virtual machine that runs macOS.

If you can’t get access to a Mac machine, you can create a virtual machine running macOS.

Creating the Flash Drive Installer

Once you have access to the macOS operating system, you can create the flash drive installer and start the installation process. Keep in mind that you’ll need to wipe the drive before you can format as GUID. And keep the flash drive installer, as you’ll need it later on.

Here’s a quick rundown of how to create the installer.

Download macOS

Open the app store, login with your Apple ID, and download High Sierra.

Format the USB

Insert the flash drive and open Disk Utility. Select the flash drive from the left column, and click erase. Adjust to the following settings:

• Name: Hackintosh
• Format: Mac OS Extended (Journaled)
• Scheme: GUID Partition Map

Next, click “Erase” and then “Done.” Feel free to change the name to whatever you wish. The Partition Map scheme will allow for am EFI partition to be created.

Create the Installer

Open Terminal and paste the following code:

• Press enter.
• Type in your password.
• Press Y when asked to erase.
• Press enter again.

Don’t remove your flash drive until the process is complete. It can take up to 60 minutes (maybe more) to copy the installer files into the USB drive.

Installing MacOS

You should now be able to install macOS High Sierra to your drive. The process will take some time to complete, depending on the type of processor you have.

Your system should restart after the installation process is completed.

Dual Boot Mac Os Sierra And Windows 10 Iso

Also, you’ll have to go through a few prompts before your machine will be ready to use macOS.

• Choose your Country, and click the “Continue” button.
• Enable Location Services, and click “Continue.”
• Sign in with your Apple ID, or choose “Don’t Sign In” and click “Continue.”
• Agree to the Terms and Conditions.
• Fill out the form, which asks for your Full Name, Account Name, Password and a Password Hint.
• Set your Time Zone based on your location.
• Choose “Continue” to create a user for your macOS.

Now, you’ll need to wait while the system sets up your macOS. This may take a while, so be patient.

Create the Windows Partition

Now that you have macOS installed, it’s time to install Windows 10.

Dual Boot Mac Os Sierra And Windows 10 Bootable

• Open Disk Utility.
• Click the View button at the top left corner of the application and select “Show All Devices.”
• Select the drive.
• Click Partition at the top of the toolbar.
• Click “+” under the circle to add a new partition.
• Give the partition a name and choose your desired size (we recommend a minimum of 50GB).
• Set the Format to ExFat.
• Click Apply.

Install Windows 10 on Your Hackintosh

Just like with macOS, you’ll need either access to Windows or to create a USB flash drive with the operating system on it. Do not wipe out the drive with macOS on it, as you’ll still need it to regain access to macOS. You will need a separate flash drive for this step.

To create the installer:

• Download Windows Installer Manager.
• Create the installer.

Next:

• Boot the “UEFI: partition” of the Windows installer. If you don’t boot the “UEFI: partition” of the flash drive, you will get an error and won’t be able to move on to the next step.
• Move through the first parts of the installation.
• When possible, choose “Custom: Install Windows only (advanced).”
• Choose the Windows partition you created in Disk Utility.
• Choose Format.
• Click OK.
• Complete the installation process.

Keep in mind that the system will restart several times during installation.

EFI Cleanup and Clover Access

After installing Windows, it’s time to move back to macOS. For this step, you will need the macOS flash installer you created earlier.

Right now, we can’t boot macOS because the Windows installer modified the EFI folder, which overrides the Clover boot loader with Windows Boot Manager. This causes the UEFI: (drive_name) to disappear from the BIOS boot devices.

In order to get things up and running smoothly, you’ll need to make some changes to the “bootmgfw.efi” file. This is the file that’s preventing access to Clover when booting the system. A simple file name change is all that’s needed to fix the problem.

• Boot the “UEFI: partition” of the macOS Installer.
• Boot macOS drive.
• Open the Clover Configurator.
• Select “Mount EFI” from the left column.
• Choose “Mount Partition” for your drive.
• Select “Open Partition.”
• Go to EFI/Microsoft/Boot/.
• Rename the “bootmgfw.efi” file to “bootmgfw-orig.efi.”

Dual Boot Mac Os Sierra And Windows 10 64-bit

When you restart, “UEFI: (drive_name)” should now be accessible.

If “UEFI: (drive_name)” is still not showing up as an available boot device, you can override the Windows Boot Manager and redirect it to Clover.

• Boot macOS off of your drive again.
• Mount the EFI partition of the boot drive using Clover Configuration.
• Open the EFI.
• Navigate to EFI/Boot.
• Copy the file BOOTX64.efi.
• Navigate to EFI/Windows/Boot.
• Past BOOTX64.efi here.
• Rename BOOTX64.efi to bootmgfw.efi.
• Restart and boot off the Windows Boot Manager. It should redirect to Clover.

Dual Boot Using Clover

Dual Boot Windows 10 And Macos High Sierra On Macbook Pro

You should now be able to dual-boot using the Clover Menu. To boot Windows, simply select Boot Windows EFI from EFI in Clover.
